Sporlan 401305 Catch-All Filter-Driers 3/8 Inch ODF Liquid Line C-303-S

Product Description

The Sporlan 401305 Catch-All Filter-Drier is a critical component for refrigeration and air conditioning systems, designed to maintain the purity and efficiency of your system's refrigerant. This model is specifically mapped for 3/8 inch ODF liquid lines and features a robust, leak-proof shell with solid copper sweat fittings.

• Optimal moisture and acid removal with molded desiccant cores.
• Includes a safety outlet filter to capture foreign particles with minimal pressure drop.
• UL Listed, compatible with all HCFC and HFC refrigerant/lubricant combinations.

Product Highlights

Recognized for its reliability and effectiveness, the Sporlan 401305 ensures cleaner refrigerant for better performance and longevity of cooling systems. Its advanced filtration technology is designed to trap contaminants, including sludge and dirt, which can degrade system efficiency.

Technical Specifications

• Connection Ends: ODF
• Size: 3/8 inch
• Capacity: 30 cu in
• Maximum Working Pressure: 650 psi
• Length: 11.5 inches
• Width: 3.5 inches
• Height: 3.5 inches
• Diameter: 3.00 inches
• Product Group: Sealed Filter-Driers
• Series-Brand: Catch-All by Sporlan Valves
