Panduit HSTT09-Y HeatShrinkThn 0.09 Dia Black

Product Description

Panduit HSTT09-Y is a heat shrink tubing with a diameter of 0.093 inches, suitable for various applications. This product is constructed of cross-linked polyolefin materials, providing reliable insulation and protection for electrical connections.

• Thin wall installation with minimal bulk.
• Resistant to harsh environments and chemicals.
• Suitable for dry locations and color coding wires.

Product Highlights

This tubing withstands temperatures ranging from -67 to 275 degrees Fahrenheit, making it effective for a wide range of electrical tasks.

Product Information

Standard Information

• Manufacturer: Panduit
• Catalog Number: HSTT09-Y

Technical Specifications

• Material: Polyolefin
• Color: Black
• Voltage Rating: 600 VAC
• Shrink Ratio: 2:1
• Length: 6 inches
• Inner Diameter Expanded: 0.093 inches
• Inner Diameter Recovered: 0.046 inches
• Wall Thickness Recovered: 0.02 inches
• Shrink Temperature: 194 degrees Fahrenheit
• Standards: UL Recognized, CSA Approved, MIL SPEC
• Application: For dry locations and insulating wires
