nVent A242008LP HOF NEMA-12 ENCL 24 in L x 20 in W x 8 in D

Product Description

nVent HOFFMAN offers the A242008LP, a medium enclosure designed for various electrical applications. This enclosure measures twenty-four inches in length, twenty inches in width, and eight inches in depth. With an NEMA 12/IP65 rating, it provides protection in environments with dust and water exposure. The enclosure features a clamp/continuous hinged cover and a panel size of seventeen inches wide by twenty-one inches high. The locking mechanism includes a hasp and staple for added security and padlocking options.

• Removable door with a continuous hinge
• Oil-resistant gasket
• External wall mounting brackets for easy installation

Product Highlights

This enclosure provides both security and functionality, making it suitable for different installations.

Product Information

Standard Information

• Manufacturer: nVent
• UPC: 78351028200

Technical Specifications

• Color: Gray
• Cover Type: Clamp/Continuous Hinged
• Depth: 8 in
• Finish: Painted
• Length: 24 in
• Lock: Hasp and Staple/Padlock
• Material: Steel
• Mounting Type: Wall
• NEMA Rating: NEMA 12/IP65
• Panel Size: 17 in W x 21 in H
• Series: A12
• Standards/Approvals: cUL Listed per CSA C22.2 File No. 94, CSA File No. 42186, IEC 60529, RoHS Compliant, UL 508A Listed File No. E61997
• Type: Medium
• Width: 20 in
