MORRIS 97112 Insulated 2 Conductor Dual Entry Splice 4 - 14 Wire Range

Product Description

The Morris Products 97112 is an insulated two-conductor splice connector designed for wires ranging from four to fourteen. It features dual entry, which allows for wire entry from both sides. This connector is rated for six hundred volts and comes pre-filled with an oxide inhibitor to enhance performance. Made from 6061-T6 Aluminum CU9AL, it is suitable for both aluminum and copper wires and can operate in temperatures from negative forty-nine to one hundred ninety-four degrees Fahrenheit.

• Insulated with high-dielectric rubber and vinyl for added protection.
• Allows easy re-entry for inspections and modifications.
• Compatible with aluminum and copper conductors.

Product Highlights

Product Information

Standard Information

• Connector Type: Splice Connector
• Terminal: Screw Terminal

Technical Specifications

• Wire Range: 4 - 14
• Conductor Type: Copper and/or Aluminum
• Material: 6061-T6 Aluminum CU9AL
• Coating: Rugged high-dielectric Rubber/Vinyl
• Temperature Range: -49°F to 194°F (-45°C to 90°C)
• Voltage: 600 Volt
• Listing: ANSI C119.4 & cULus 486B
• Certification: UL/CSA Certified through 750MCM size
• Usage: Indoor Use Only
• Rated Voltage: 600V
• Number of Ports: Two
• Allen Type: Slotted
• Oxide Inhibitor: Yes: Pre-Filled
• Input Wire Range: 4-14
• Operating Temperature: -49°F to 194°F (-45°C to 90°C)
• Environment: Dry Location
