Milwaukee UP0969000200 Valve 2-Inch Horizontal Swing Check Valve

Product Description

The Milwaukee Valve UP0969000200 is a two-inch horizontal swing check valve suitable for potable water applications. It is made from lead-free brass and incorporates a press connection type with EPDM softgoods. This valve allows flow in one direction, effectively preventing backflow in water systems. It meets NSF/ANSI 372 standards, ensuring safety and reliability.

• Body material: Lead-free brass
• Connection type: Press
• Maximum pressure: 200 psi at 250 degrees F

Product Highlights

This valve is ideal for horizontal mounting and ensures compliance with safety standards.

Product Information

Standard Information

• Country of Origin: CN
• Application: Potable Water

Technical Specifications

• Item: Swing Check Valve
• Mechanism and Body Design: Horizontal Swing
• Body Material: Lead Free Brass
• Pipe or Tube Size: 2 in
• Connection Type: Press x Press
• Maximum Temperature: 250 Degrees F
• Maximum Water Pressure: 200 psi
• Pressure Rating: 200 psig
• Seat Material: Brass
• Overall Height: 2 31/64 inches
• Length: 7 5/32 inches
• Cap to Inlet Center: 2 12/25 inches
• Hex Size: 4 inches
• Domestic/Import: Import
• Inlet to Outlet Length: 7.16 inches
• Low Lead Compliance: Yes
• Media: Water
• Series: UP969
• Softgoods Material: EPDM
• Trim Material: Brass
• Type: Horizontal
