Product Description
The Mersen ATMR20 is a robust low-voltage general purpose fuse designed for fast-acting performance in both AC and DC applications, up to 600 volts and 20 amperes. This Class CC fuse is configured for use in branch circuits, control circuits, and circuit transformers, showcasing versatility across multiple electrical environments.
- Compact design suitable for space-limited installations
- Exceptional reliability in industrial settings with a fiberglass body and rejection style design
- Fast-acting interruption of excessive currents, ensuring safety and component protection
Product Highlights
The ATMR20 enhances system integrity with its rejection-style build, preventing installation errors and compatibility issues in specified fuse blocks. Its fiberglass body ensures stability and endurance under harsh conditions.
Product Information
Standard Information
-
Type: Class CC Low Voltage Fuse
-
Application: Suitable for control circuits, lighting, general loads, and specific industrial applications
Technical Specifications
-
Voltage Rating: 600V AC/DC
-
Amperage Rating: 20A
-
Interrupt Rating: 200 KA AC, 100 KA DC
-
Fuse Size: 1.5 inches x 0.41 inches
-
Mounting Style: Clip
-
Connection Type: Ferrule
-
Technical Compliance: UL Listed, CSA certified
-
Manufactured In: Mexico
