McGuire LFST17LK Straight Supply Stop Valve 1/2 In x 3/8 In OD

Product Description

The McGuire LFST17LK is a straight supply stop valve with a 1/2 inch nominal inlet and a 3/8 inch OD outlet. This valve is made from machined brass and has a chrome-plated finish. It allows for full-turn operation with a loose key handle.

• 1/2 inch nominal inlet and 3/8 inch OD outlet
• Brass construction with chrome plate
• Designed for full-turn operation with a loose key

Product Highlights

This valve is essential for reliable shutoff applications, enabling users to manage water flow seamlessly. It is ideal for use in plumbing systems and can handle a range of operating conditions.

Product Information

Standard Information

• Brand: McGuire Manufacturing
• MPN: LFST17LK

Technical Specifications

• Type: Straight
• Style: Standard Pattern
• Inlet Size: 1/2 inch
• Inlet Type: Nominal
• Outlet Size: 3/8 inch
• Outlet Type: OD
• Material: Brass
• Body Material: Machined brass
• Handle Material: Chrome Plated Zinc
• Finish: Chrome Plated
• Handle Type: Loose Key
• Operation Type: Full turn
• Operating Temperature Min: 40 °F
• Operating Temperature Max: 140 °F
• Maximum Temperature: 180 °F max during high-temperature system flush
• Operating Pressure Max: 125 psi
• End Connection 1: Compression
• End Connection 2: OD Tube
• End Connections: Compression x OD Tube
• Valve Type: Straight Supply Stop Valve
• Valve Size: 1/2 inch x 3/8 inch
• Length: 1.625 inches
• Height: 2.25 inches
• Weight: 0.36 pounds
• Industry Standards/Certifications: AB100 Compliant: NSF/ANSI/CAN 61: Q < 0.5 µg
• Stem Material: Brass
• Stem Type: Brass
• Stem Washer Material: EPDM Peroxide Cured
• Handle Screw Material: Brass
• Lead Law Compliant: Yes
• Color Finish Category: Chromes
• Color Finish Name: Chrome Plated
