Azure by Mars 10870 Digi-Motor 1/3 to 1/2 hp 230 VAC 50/60 Hz

Product Description

The Azure by Mars Digi-Motor 10870 is designed for condenser fan applications. This electronic motor runs at 1/3 to 1/2 horsepower with a voltage rating of 230 VAC. It operates at speeds of 825 or 1075 rpm and features both clockwise and counterclockwise rotation. The design includes a closed air over enclosure, a ball bearing setup, and requires stud mounting for easy installation.

• High efficiency ECM technology
• Easy installation without a capacitor
• Includes a replaceable outboard surge protector

Product Highlights

This motor is versatile for numerous HVAC applications. It supports multiple operating modes, providing simplicity in setup by connecting to a standard power source. The Azure Digi-Motor is engineered for durability, operating in temperatures ranging from -32 to 55 degrees Celsius and featuring insulation class B. The inclusion of a water slinger helps enhance reliability.

Product Information

Standard Information

• Brand: Azure by Mars
• Manufacturer: Mars

Technical Specifications

• MPN: 10870
• Horsepower: 1/3 to 1/2 hp
• Voltage Rating: 230 VAC
• Speed: 825/1075 rpm
• Phase: 1 ph
• Dimensions: 5-1/2 in Dia
• Shaft Size: 0.5 in Dia x 6.96 in L
• Rotation: CW/CCW
