iO HVAC Controls HD-1008 10 Inch X 8 Inch 2-wire, Two-Position Rectangular Motorized Zone Damper

iO HVAC Controls HD-1008 10 Inch X 8 Inch 2-wire, Two-Position Rectangular Motorized Zone Damper, replacement for Honeywell ZD10X8TZ, EWC ND-RSD1008, Zone First ZDS-1008

SKU: HD-1008
Availability: In Stock
Ships in 4 - 5 Business Days
$195.17
$195.17
HAVE A QUESTION?

Our team is ready to help!

  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

iO HVAC Controls HD-1008
10 Inch X 8 Inch 2-wire, Two-Position Rectangular Motorized Zone Damper Features:
- 10 inch X 8 inch rectangular.
- 5 year warranty.

DIMENSIONS:
-Damper models HD-XXXX are sized width (A) by height (B) with actuator on the (B) dimension.
- Bottom mount models HD-XXXX-BM are sized width (A) by height (B) with actuator on the (A) dimension.
- Actual (A) and (B) dimensions are undercut 1/4”.
- Standard sizes range from 8” x 8” up to 36” x 24” in 2” increments.

APPLICATION:
- Compatible for zone control and other HVAC applications with static pressures less than 1.0” w.c.

CONSTRUCTION:
- 1/16” extruded aluminum frame
- 1/16” extruded aluminum parallel blades
- 1/16” aluminum mounting flange
- Nylon bushings
- Minimum position adjustment

ELECTRICAL:
- 24 Volt, 10 VA, 0.43 Amp powered closed, spring return open actuator
- Also available in powered open, spring return closed
- Motor is impedance protected with no end switches

HD Series The HD Series dampers are extruded aluminum parallel blade dampers complete with a 24 volt spring return actuator. The HD Series dampers can be installed in any position and are compatible with most 24V zoning and ventilation controls. They are rated for duct systems less than 1.0” WC. These dampers have a simple adjustment for limited position. They are a highly universal option for both zoning an ventilation applications.
