Intermatic FD2HW 2 Hour Auto-Off Springwound Timer

Product Description

The Intermatic FD2HW is a 2-hour auto-off spring wound timer designed for reliable operation in various applications. This model is suitable for controlling lighting, fans, and motors without requiring electricity. It can replace any standard wall switch, making it ideal for single or multi-gang setups. With the FD2HW, you can automatically limit the ON time for energy-consuming devices like heaters and fans.

• Mechanical design; no electricity required for operation
• Automatically limits ON times for various loads
• Easy installation with teeter-type terminals

Product Highlights

This timer is perfect for indoor use and supports incandescent, fluorescent, CFL, and LED bulbs.

Product Information

Standard Information

• Brand: Intermatic
• Catalog Number: FD2HW

Technical Specifications

• Voltage Rating: 125 - 277 VAC
• Amperage Rating: 15 Amps
• Contact Rating: 7 A at 125 VAC (Tungsten), 20 A at 125 VAC (Resistive)
• Operating Temperature: -40 to 104 degrees F
• Mechanical Type: SPST (Single-Pole Single-Throw)
• Size: 2.79 inches height x 1.6 inches width x 1.19 inches depth
• Weight: 0.299 lb
