Honeywell M7294Q1015 NSR Actuator 24V 300 lb-in 4-20 mA Control

Product Description

The Honeywell M7294Q1015 non-spring return actuator is designed for industrial automation applications. This actuator operates with a 24V signal and provides a 4-20 mA control. Suitable for tasks requiring precision and reliability, it features dual auxiliary switches and foot mounting.

• Electric non-spring return actuator
• 24V and 4-20 mA control
• 300 lb-in torque

Product Highlights

The Honeywell M7294Q1015 actuator is built for controlling dampers and valves in various industrial settings. It ensures high performance and durability, backed by robust construction suitable for harsh environments.

Product Information

Standard Information

• Brand: Honeywell
• Item Number: M7294Q1015
• Application: Industrial automation, valve control, robotics, material handling

Technical Specifications

• Fail Safe Mode: Non-Spring Return
• Control Signal: Modulating, 4-20 mA
• Motor Shaft: Dual ended Shaft
• Stroke: Adjustable; 90 to 160 degrees, Symmetrical
• Frequency: 50 Hz, 60 Hz
• Power Consumption: 15 VA
• Shaft Dimensions: 0.375 in, Square
• Dimensions: 6 7/16 in. high x 5 1/2 in. wide x 8 3/4 in. deep
• Temperature Range: -40 to 150F
• Deadweight Load on Shaft: 200 lbs (Either End), 300 lbs (Combined)
• AUX Switch Ratings: 120 Vac (7.2A), 240 Vac (3.6A)
