Dodge 4B9.4-2517 SHEAVE - 118096 Bushing Bore V-Belt Pulley

Product Description

The Dodge 4B9.4-2517 SHEAVE is designed for effective power transmission in machinery. This V-belt pulley fits A and B belt sections and features a 4 groove design. With a pitch diameter of 9.38 inches for A and 9.76 inches for B, it offers durability and reliability for various applications.

• Isolates shock loads and vibration.
• Requires low maintenance and no lubrication.
• Efficient drive ratios of six to one or more possible.

Product Highlights

The sheave is efficient with a typical efficiency of 95%. It operates quietly, ensuring that motor noise does not interfere with operations. Taper lock bushings are required for installation.

Product Information

Standard Information

• Brand: Dodge
• Country of Origin: United States

Technical Specifications

• Weight: 22.55 lbs
• Face Width: 3.2500 inches
• Overall Width: 3-1/4 inches
• Bushing Series: 2517
• Pitch Diameter: 9.38 inches (A), 9.76 inches (B)
• Outside Diameter: 9.7500 inches
• Number of Grooves: 4
• Bushing Bore Range: 1/2 to 2-11/16 inches
• Length Through Bore: 1.7500 inches
