Delta 101LF-HDF Kitchen Faucet HDF 1 Lever Swivel 180 Degree 1 Hole

Product Description

The DELTA 101LF-HDF kitchen faucet features a one lever handle, a chrome finish, and a 180-degree swivel spout. Designed for one-hole installation, this faucet offers a practical solution for any kitchen. It is ADA compliant and WaterSense certified. The DIAMOND Seal Technology ensures lasting performance.

• One lever handle
• Chrome finish
• 180-degree swivel spout
• One-hole installation

Product Highlights

Features a vandal-resistant handle and aerator. Includes straight, staggered supply tubes and 3/8" O.D. inlets with 3/8" fittings, including 1/2" adapters.

Product Information

Standard Information

• Brand: DELTA
• Manufacturer Part Number: 101LF-HDF
• Country of Origin: United States

Technical Specifications

• Brand: Delta
• Number of Handles: Single Handle
• Handle Type: Lever
• Finish: Chrome Plated
• Spout Type: Swivel
• Number of Holes: 1 Hole
• Spout Reach: 8-69/100 in
• Flow Rate: 1.5GPM
• Inlet Size: 1/2IN
• Inlet Connection: NPSM
• Length: 9-1/3IN
• Width: 2IN
• Height: 8.375 in.
• Model / MPN: 101LF-HDF
• Manufacturer: Delta Faucet
• GPM: 1.5
• Type: Single Hole Faucets
• FinishColor: Polished Chrome
• Finish_Name: Chrome
• Handle_Type: Single Handle Lever
• Faucet_Hole_Center: Single Hole
• Number_of_Faucet_Holes: 1
• Commercial_or_Residential: Primarily Residential
• Item: Low Arc Kitchen Faucet
• Series: HDF
• Features: NA
• Includes: Diamond Seal Technology
• Mounting: Deck
• Standards: ASME A112.18.1/CSA B125.1, ANSI A117.1
• Connection: 3/8"
• Valve Type: Ceramic Disc
• Depth (In.): 9.31
• Faucet Type: Kitchen Sink Faucet
• Faucet Spout: Swing
• Spout Height: 3-3/4 in
• Spout Length: 8-11/16"
• ADA Compliant: Yes
• Body Material: Brass
• CEC Compliant: CEC Compliant
• Faucet Finish: Chrome
• Mounting Type: Deck Mount
• Connection Size: 3/8"
• Flow Rate (GPM): 1.5
• Faucet Operation: Manual
• Flow Outlet Type: Aerated
• Faucet Activation: Manual
• Faucet Handle Type: Lever
• Faucet Spout Shape: Low Arc
• Ligature Resistant: No
• Overall Width (In.): 2
• Temperature Control: Yes
• Faucet Body Material: Brass
• Overall Height (In.): 7.81
• Valve Type - Faucets: Hot/Cold Cartridge
• Replacement Cartridge: RP50587
• Faucet Handle Material: Metal
• Mounting Type - Faucet: Deck
• Residential / Commercial: Commercial
• Flow Outlet Type (Faucet): Aerated
• Vandal Resistant Features: Vandal Resistant Outlet
• Manufacturers Warranty Length: Lifetime (Parts)
• Mounting Hole Center to Center: 8"
• Max. Mounting Hole Center Distance: Single Hole
• Max. Installation Surface Thickness: 2.5"
• Country of Origin (subject to change): United States
• Replacement Cartridge Mfr. Model Number: RP50587
• Green Certification or Other Recognition: California Energy Commission (CEC) Certified
• Material: Brass
• Installation Type: Deck Mounted
• Handle Style: Lever
• Connection Type: Universal fittings
• Overall Height (in.): 7-13/16
• Control Box Option: N/A
• Installation Center: 8" (203mm) Centers
• Overall Height: 8-3/8" (measured from counter top to highest point of faucet)
• Number of installation holes required: 1
• Installs onto decks up to: 2-1/2" thick
• Handles Included: 1
• Low lead compliant: complies with federal and state regulations for lead content
• Designed to easily connect to: standard U.S. plumbing supply bibs
• Extra secure mounting assembly: Yes
• All necessary mounting hardware included: Yes
• Faucet Centers: 0 in.
• Faucet Hole Size: 1.375 in.
• Max Deck Thickness: 2.5 in.
• Spout Swivel: 180°
• Escutcheon Included: No
• Filtering: No
• Sidespray: No
• Soap Dispenser Included: No
• Valve Included: Yes
• Pre Rinse: No
• Pullout Spray: No
• Theme: Basic
• Water Efficient: Yes
• Manufacturer Technology: Diamond Seal
• ADA: Yes
• Approved for Commercial Use: Yes
• CA Drought Compliant: Yes
• Collection: HDF Commercial®
• Eco Friendly: Yes
• Made in America: Yes
• Manufacturer Warranty: 5 Year Limited Commercial, Limited Lifetime Residential
• Recommended Uses For Product: Kitchen
• Finish Type: Chrome
• Included Components: Handle
• Hole Count: 1
• Special Feature: ADA Compliant
• Style: Classic
• Maximum Flow Rate: 1.5 Gallons Per Minute
• Model Name: 101LF-HDF
• Handle Material: Brass
• Handle Location: centerset
• Spout Design: Low Arc
• Room Type: Kitchen
• Special Features: ADA Compliant
• Batteries Included?: No
• Batteries Required?: No
• Warranty Description: Limited Commercial 5-year Limited Warranty
• ANSI: ANSI A117.1
• ASME: ASME A112.18.1
• Application: Commercial
• For Sale in CA: Yes
• CSA Certified: Yes
• Color Finish Category: Chromes
• Color Finish Name: Chrome
• Deck Plate Included: No
• Faucet Connection: OD Tube
• Faucet Connection Size: 3/8 in
• Faucet Height: 8-1/2 in
• Faucet Material: Brass
• Faucet Mount: Deck Mount
• Faucet Valve Type: Diamond Coated Ceramic Disc
• GSA Approved: No
• Handle Included: Yes
• IAPMO Listed: Yes
• Lead Law Compliance Level: Lead Free and Lead Leaching Compliant
• Lead Law Compliant: Yes
• NSF: NSF 61
• NSF Certified: Yes
• Side Spray: No
• UL Listed: No
