CARRIER T812C1000 Non-Programmable Thermostat

Product Description

The CARRIER T812C1000 is a non-programmable thermostat tailored for 1-stage heating and cooling systems. It operates well in an eighteen to thirty Vac voltage range. This thermostat has a bimetal sensor for precise temperature detection and boasts a temperature setting range of forty-five to ninety-five degrees Fahrenheit with an accuracy of plus or minus three degrees Fahrenheit.

• Supports 24V heat and cool operation for efficient temperature control.
• Utilizes a snap-acting thermostat for reliable temperature regulation.
• Features an easy-to-read display for monitoring temperature.

Product Highlights

Ideal for residential and light commercial applications, the CARRIER T812C1000 provides straightforward operation with an OFF-HEAT-COOL AUTO-ON switch for seamless system management.

Product Information

Standard Information

• Brand: CARRIER
• Model Number: T812C1000

Technical Specifications

• Temperature Setting Range: 45°F to 95°F (7°C to 35°C)
• Switching Action: SPDT
• Operating Humidity Range: 5% to 90% Relative Humidity
• Dimensions: 3 1/8 inches high x 3 1/8 inches wide x 7/8 inches deep
• Electrical Rating: 18 to 30 Vac
• Stages: 1 Heat / 1 Cool
• Sensor Element: Bimetal
• Switch Type: Snap action
