CARRIER 1191329 Condenser Fan Motor 1/5 HP

Product Description

The CARRIER 1191329 Condenser Fan Motor is built for condenser fan tasks. This single-phase motor is made by Broad-Ocean and works at 208-230 VAC and 60 Hz. It provides 1/5 horsepower at 1100 RPM, with a current draw of 1.05 amps. The motor features clockwise rotation and has a 1/4-inch diameter shaft with a length of 2-3/4 inches. It comes with thermal protection and insulation class B, making it suitable for continuous air over applications. The motor stands at a height of 4-1/2 inches and includes leads that are 44 inches long.

• Operates at 208-230 VAC and 60 Hz
• Delivers 1/5 horsepower at 1100 RPM
• Includes thermal protection and insulation class B

Product Highlights

This motor is essential for efficient condenser fan operation.

Product Information

Standard Information

• Manufacturer: Broad-Ocean
• GTIN: 0 08 23960 41284 9

Technical Specifications

• Horsepower: 1/5
• RPM: 1100
• Voltage: 208-230
• Hertz: 60
• Current: 1.05 Amps
• Number of Phases: 1
• Number of Speeds: 1
• Rotation: Clockwise
• Shaft Diameter: 1/4 inches
• Shaft Length: 2-3/4 inches
• Height: 4-1/2 inches
• Thermally Protected: Yes
• Lead Length: 44 inches
• Insulation Class: B
• Continuous Air Over: Yes
