CARRIER 1172506 HVAC Relay 24V DPST

Product Description

The CARRIER 1172506 is a 24V DPST relay made for HVAC applications. This relay controls blower motors and compressors, ensuring efficient operation. It is compatible with Carrier, Bryant, and Payne HVAC models.

• Operates at a control voltage of 24 VAC.
• Rated for 30A at 277 VAC, 20A at 28 VDC, 1HP at 120 VAC, 3HP at 240 VAC, and TV10 at 120 VAC, 22 VDC.
• Includes quick-connect terminals for easy installation.

Product Highlights

This relay is designed for multi-purpose electrical applications within specified voltage and amperage ranges.

Product Information

Standard Information

• Brand: CARRIER
• MPN: 1172506

Technical Specifications

• Control Voltage: 24 VAC
• Dimensions: Length 2.75 inches, Width 1.38 inches, Height 1.5 inches
• Weight: 0.001 pounds
• Relay Type: Multi-Purpose
• Max Ratings: 30A 277 VAC, 20A 28 VDC, 1HP 120 VAC, 3HP 240 VAC
• Country of Origin: USA
• UOM: EA
