CaptiveAire BG100-35 Pre Drilled Orifice for Indirect Gas Furnaces Used for Ibts

Product Description

The CaptiveAire BG100-35 is a pre-drilled orifice designed for indirect gas furnaces used specifically for IBTS systems. This component is vital for the efficient operation of natural gas units operating at high altitudes. The drill size is #35, suitable for NG 500,000 to 200,000 BTU HMA units at elevations exceeding 10,000 feet. It is also compatible with NG 685,000 BTU HMG units operating at altitudes between 2,000 and 3,999 feet.

• Compatible with IBTS systems for improved efficiency.
• Essential for specific altitude applications.
• Durable design to support high BTU ratings.

Product Highlights

This product provides reliable performance for users needing compliance with specific gas furnaces. Its design accommodates varying elevations, ensuring optimal gas flow and combustion.

Product Information

Standard Information

• Brand: CaptiveAire
• Part Number: BG100-35

Technical Specifications

• Drill Size: #35
• BTU Rating: 500,000 - 200,000 BTU
• Altitude Compatibility: >10,000 ft and 2,000-3,999 ft
