Bussmann SC-25 Bussmann Series SC-25 Class G Fuse 25 A 480 VAC 100/10 kAIC

Product Description

Bussmann Series SC-25 Class G Fuse is a 25 Amp current limiting time-delay fuse designed for effective circuit protection. The SC-25 fuse is a reliable component for HVAC branch circuit protection and fusible branch panelboards. Its applications include general purpose uses where overcurrent protection is required.

• Current limiting and non-indicating style
• Ferrule end terminations for secure connections
• High interrupt ratings of 10 kAIC at 300 VDC and 100 kAIC at 480 VAC

Product Highlights

This fuse features a compact cartridge design, ensuring effective operation in various circuits.

Product Information

Standard Information

• Brand: Bussmann
• Manufacturer: Bussmann Mfg.

Technical Specifications

• MPN: SC-25
• Current Rating: 25 Amp
• Type: Current Limiting Time Delay
• Voltage Rating: 480 VAC
• Interrupt Rating: 100/10 kAIC
• Class: G
• Body Size: 0.41 inches diameter x 1.62 inches length
• Material: Melamine
• End Type: Ferrule
• Response Time: 12 seconds at 200%
