BURNDY 1PLD42 Al Multi-Port Distribution Tap Connectors, 2 Ports, 600 V

Product Description

The BURNDY 1PLD42 is an aluminum multi-port distribution tap connector designed for indoor use. This product features a UV black plastisol covering and is compatible with conductor sizes ranging from fourteen to four AWG. The product supports double-sided entry and has a maximum voltage of six hundred volts.

• Two ports for connections
• UV rated for durability
• Pre-installed oxide inhibitor for moisture protection

Product Highlights

This connector is ideal for efficient wiring, reducing the need for multiple connectors while ensuring safety and reliability. It is a market-preferred solution for electricians and HVAC professionals.

Product Information

Standard Information

• Manufacturer: Burndy, a Hubbell affiliate
• Country of Origin: United States

Technical Specifications

• Catalog Number: 1PLD42
• Material: Aluminum
• Application: For indoor use only, copper or stranded aluminum
• Special Features: UV rated plastisol, oxide inhibitor, range-taking capability, UL486B listed
• Conductor Size Range: 14 – 4 AWG
• Number of Ports: 2
• Insulation Type: UV rated plastisol
• Temperature Rating: 194 degrees
