America BL6414 5inch Single Shaft Open Fan/Blower Motor 115V 1/5, 1/8, 1/10 HP

Product Description

The America BL6414 is a five-inch single shaft open fan/blower motor that operates at 115V. This motor is capable of delivering one-fifth, one-eighth, and one-tenth horsepower. It comes with an open enclosure design and includes automatic overload protection, making it suitable for various applications such as furnace blowers, attic ventilators, and air handlers.

• Power Options: 1/5, 1/8, 1/10 HP
• RPM: 1050
• Includes resilient mounting rings

Product Highlights

This motor is designed for efficiency and durability, perfect for HVAC systems and other ventilation needs.

Product Information

Standard Information

• Type: Shaded Pole
• Horse Power: 1/8, 1/5, 1/10

Technical Specifications

• Voltage: 115V
• Duty: Air Over
• RPM: 1050
• Poles: 6
• Mount: Resilient Rings
• Rotation: CCWLE
• Hertz: 60
• Speeds: 3
• Amperage: 4, 6.5, 3
• Frame: 42Y
• Phase: 1
• Insulation Class: A
• Diameter: 4-7/8 inches
• Overload Protection: Automatic
• Max Ambient Temp: 104°F
• Motor Orientation: Horizontal
• Output KW: 0.15 kW
• Service Factor: 1
• Frequency: 60 Hz
• Current: 6.5, 4.0, 3.0 A
• UL: Recognized
• CSA: Y
• CE: N
